MAIN PURPOSESIt is used for washing, drying glasses, manuel assembling and pressing between rollers.GENERAL SPECIFICATIONS• Surfaces which contacts directly with water are made of stainless steel
• User friendly control panel
• Self adjustment system for glass thickness
• 19 mm thickness processing
• Stainless water pumps
• Outlet filters for water pumps
• Special design for conveyor wheels to move heavy glasses
• Individual spindles for each brushes
• Brush shafts are balanced against vibration
• Ability of washing coated glasses with staple type brushes
• Easy cleanable water nozzles are positioned with a wide angle for drag effect
• Wiper rubbers and brushes between sections in the washing unit
• 2 sectioned stainless water tank with capacity of 300 lt (1 of the tanks are with heater)
• Water level control with magnetic safety sensors
• Automatic water support system with float control
• Stainless water filters
• Conveyor system without touching to side carrier wheels at drying section
• Valve system for energy saving when there is no glass in drying unit
• Stopping of brushes and water pumps when there is no glass in the washing unit or conveyor wheels are stopped
• Drying unit with noise isolation and fan cabinet with heat control
• Ability of manufacturing double and triple glasses manually
• Delivery of second or third glass from outlet rack to spacer bar assembling unit with movable rack mechanism
• Carrying system of second or third glass on the spacer bar assembling unit with free wheels
• Height and depth adjustable side and lower supporters at spacer bar assembling unit
• Pressing by different pressures at vertical and horizontal axes between rotating rollers
• Adjustable period of pressing at vertical axisOPTIONS, ADVANTAGES AND DIFFERENCES• Completely stainless washing cabin
• Sand filter with 25 micron accuracy
• Water purification unit
• Tilting table at the end of press unit
• Ability of manufacturing triple glass
